| Device | Datasheet | Frequency | Stability(PPM) | Output Type | Supply Voltage(V) | Temp. Range(°C) | Package Size(mm2) |
|---|---|---|---|---|---|---|---|
| SIT8924 | 1MHz - 110MHz | ±20 ±25 ±30 ±50 | LVCMOS | 1.8,2.5 2.8,3.0 3.3,2.25~3.63 | -40 ~ +85 -40 ~ +105 -40 ~ +125 -55 ~+125 | 2.0x1.6 2.5x2.0,3.2x2.5 5.0x3.2,7.0x5.0 | |
| SIT8925 | 115MHz - 137MHz | ±20 ±25 ±30 ±50 | LVCMOS | 1.8,2.5 2.8,3.0 3.3,2.25~3.63 | -40 ~ +85 -40 ~ +105 -40 ~ +125 -55 ~ +125 | 2.0x1.6 2.5x2.0,3.2x2.5, 5.0x3.2,7.0x5.0 | |
| SIT2024 | 1MHz - 110MHz | ±20 ±25 ±30 ±50 | LVCMOS | 1.8,2.5 2.8 3.0 3.3,2.25~3.63 | -40 ~ +85 -40 ~ +105 -40 ~ +125 -55 ~ +125 | 2.9 x 2.8（SOT23-5） | |
| SIT2025 | 115MHz - 137MHz | ±20 ±25 ±30 ±50 | LVCMOS | 1.8,2.5 2.8,3.0 3.3,2.25~3.63 | -40 ~ +85 -40 ~ +105 -40 ~ +125 -55 ~ +125 | 2.9 x 2.8（SOT23-5） | |
| SIT1625 | 44个标准频率 | ±25 ppm (85ºC) ±30 (105ºC) ±50 (125ºC) | LVCMOS | 1.5 ±10% 1.8 ±10% 2.5 ±10% 3.3 ±10% 1.62 to 3.63*1.2 ±5% | -40 ～ 85 (Gr.3) -40 ～ 105 (Gr.2) -40 ～ 125 (Gr.1) | 1.6x1.2，2.0x1.6 2.5x2.0，3.2x2.5 |
| Device | Datasheet | Frequency | Stability(PPM) | Output Type | Supply Voltage(V) | Temp. Range(°C) | Package Size(mm2) |
|---|---|---|---|---|---|---|---|
| SIT9386 | 1MHz - 220MHz | ±25 ±50 | HCSL/LVDS/LVPECL | 2.5,2.8,3.0,3.3 | -40 ~ +85 -40 ~ +105 | 3.2x2.5,7.0x5. | |
| SIT9387 | 220MHz - 725MHz | ±10 ±20 ±25 ±50 | HCSL/LVDS/LVPECL | 2.5,2.8,3.0,3.3 | -40 ~ +85 -40 ~ +105 | 3.2x2.5,7.0x5.0 | |
| SIT9396 | 1 to 220 MHz | ±30 ±50 | LVPECL, LVDS, HCSL | 1.71 to 3.63 | -40 to +85 -40 to +105 -40 to +125 | 2.0 x 1.6 2.5 x 2.0 3.2 x 2.5 | |
| SIT9397 | 220 to 920 MHz | ±30 ±50 | LVPECL, LVDS, HCSL | 1.71 to 3.63 | -40 to +85 -40 to +105 -40 to +125 | 2.0 x 1.6, 2.5 x 2.0, 3.2 x 2.5 |
